| Chassis type |
BZC5070 military 6.5T class 4×4 off-road chassis |
| Engine type |
Cummins ISDE180-30 EFI, turbocharged, Bosch co mmon rail system, intercooled diesel engine |
| Rated power |
|
| rank |
132kW |
| Engine speed |
2500r/min |
| Drive form |
4x4 |
| Displacement |
4.5L |
| Fuel consumption |
20L/100km |
| Engine fuel type |
Diesel |
| Full load total weight |
6500kg |
| Maintenance weight |
5300Kg |
| Loading weight |
1200Kg |
| Overall dimensions (L× W × H) |
5360mm×2320mm×2150mm |
| Wheelbase |
3310mm |
| Wheel base |
Front: 1785mm Middle: 1785mm |
| Minimum ground clearance |
650/1200-1700N.m/rpm |
| Maximum speed |
105km/h |
| Fording depth |
1.2 m |
| Passenger capacity |
2+9 persons (including pilot and co-pilot) |
| Tire model |
37×12.5R16.5 radial bulletproof tires |
| Fuel tank capacity (L) |
120L |
| Maximum range |
600km |
| Protection performance |
100m distance can resist 56 7.62mm ordinary bullets |
| Minimum ground clearance |
250mm |
| Maximum climb |
60% |
|
|
