Product introduction

The emergency power supply vehicle uses the second-class chassis as a modified platform, equipped with 200kW generators, silent compartm ents, output cables and other facilities, and can provide power for the site in the event of natural disasters, accidents, social security incidents and other public emergencies.

Main function

1.[Power Supply Function]

more reliable power supply and more secure power consumption

The 200KW high-power generator is equipped with output interfaces of different capacities and cable reels to meet the power supply need of different equipment.

2.[Noise Reduction System]

Intelligent mute and noise reduction strength escort rescue

Equipped with a noise reduction processing system to ensure the best mute effect of the vehicle as a whole.

Product characteristics

Product Features Introduction

Large-capacity fuel tank, domestic water tank, steaming, boiling, frying and cooking functions, integral range hood, auto water-saving circulating stove cooling function.

Product parameter

Fire emergency power supply main parameters

Chassis brand and model SITRAK ZZ1186K501GF1

L*W*H (mm) 9350,9297X2530X3925,3832

Gross mass (T); 15800

Available power supply (kW) 200

Product introduction

Non-road fuel-oil mine transporter is a cost-effective and reliable non-road diesel-driven mine dump truck developed by Chongqing Juntong A utomobile Co., Ltd., with experience accumulated for years in automobile manufacturing and refitting. It is mainly used in transportation of ce ment building material, aggregated sand and gravel mines, metal mines, water conservancy projects, construction sites and material under th e like heavy-duty downhill condition.

Product characteristics

1.High reliability chassis

adopt non-road high-HP engine above 560KW, not restricted by the fourth stage of non-road mobile machinery emission standard, strong pow er, reliable fuel-saving for "environment protection and reliability; enhanced mine-specific gearbox, high torque, low noise; newly designed axl e for more reliable load-bearing and braking capacity.

2.High safety

optimize the anti-collision system design of bumper through beam for more excellent safety protection performance; with full hydraulic steeri ng system, for easy, reliable and safe operation.

3.High-strength design

use a large number of high-strength steel plates and wear-resistant steel plates to optimize the frame design and increase the strength of carri age.

4.Comfortable handling

The brand-new cab is provided with a four-point floating design, wide perspective, optimized heat insulation and sealing design, making each occupant feel more comfortable.

Product parameter

Main parameters of transport equipment for non-road fuel mines

Driving Type 6x4

Engine Xichai 560(KW)

Emission level Non-road 3rd Stage

Gearbox FAST 8-gear AMT

Tyre size 1600R25 Special Tyre for Mining

Axle loading capacity (front + intermediate + rear) Handel 25+40+40(T)

Boundary Dimension L*W*H 9530x3750x4200(mm)

Overall Kerb Mass/ Maximum Gross Mass FAST 8-gear AMT

Max. gradeability 30(%)

Max. speed ＞40Km/h

Volume of carriage (level loading, earthwork) 40m³

Empty dimension inside compartment (L*W*H) 6000x3500x1900（mm）

Product introduction

The UAV truck is provided with a single-row and 4WD Great Wall chassis, which has the characteristics of large load capacity, strong power and strong trafficability. The vehicle is equipped with a vehicle-mounted generator, inflator pump, communication and lighting integrated system, which can meet the long-term field operation requirement of UAV truck.

Product characteristics

1.High integration Modular design

2.Rapid deployment - Strong adaptability

Product parameter

Uav equipment vehicle main configuration

Total dimension of pickup shelter L:5940mm, W: 1942mm, H: 2350mm

Number of 50kg fire-fighting UAVs 1

Number of fire extinguishing tanks 10 (5 water tanks, 5 powder-spraying tanks)

Drone batteries 16 (4 groups)

DN40 Ultra Light Fire Hose 100m

1000w vehicle-mounted lift-type lighting lamp 1

UAV command system 1

Vehicle-mounted battery (180AH) 1

Vehicle-mounted generator 1

Vehicle-mounted inflator pump 1

Charging case 2

Product introduction

Quanzelong amphibious all-terrain vehicle has a wheeled 8x8 AWD chassis and an independent suspension system, which has excellent amphi bious maneuverability. As an important equipment for the emergency rescue force, a large-sized wheeled 360o U-turn in-situ and 90o unilatera l steering or the like patented technologies adopted for the first time can cooperate with various mission platforms to complete various tasks s uch as assault rescue, real-time information transmission and underwater obstacle detection, for driving on various roads such as cities, count ryside, deserts and mud as well as various waters such as lakes, reservoirs, rivers and so on. It can be used to transport materials and manpowe r for emergency rescue, disaster relief and flood fighting.

Product characteristics

Long-row alarm light, 100W alarm. Install flashing lights, side lights, safety marker lights, and front and rear corridor combined lights around th e vehicle. The bodywork is sprayed with paint in standard rescue vehicle color.

Product parameter

Amphibious rescue vehicle

Engine 6-cylinder engine with power ≥300HP

Acceleration time (0-32km/h)<20s

Fuel Type/Tank Capacity Diesel/≥200L

Gearbox CVT + three-speed pneumatic box

Braking distance 30km rough speed: <10m

Land-drive form 8-wheel drive

Vehicle load Land/Water: Material ≥3T, Personnel ≥40

Velocity ≥40km/h; Water: ≥12km/h

Vertical obstacle-climbing capability ≥350mm

Towing capacity ≥3000kg

Max. gradeability ≥35°

Approach Angle/Departure Angle >45°(±1°)/>40°(±1°）

Min. Turning Radius on Land 0M

Product introduction

As an integrated mobile pump truck, the emergency smart water supply truck can not only meet the need of disaster relief and domestic water supply guarantee in mountainous and remote disaster areas, but also be used as an emergency fire truck for super high-rise buildings, a fractur ing pump truck for oil and gas fields, and a decontamination vehicle for radioactivity elimination and disinfection. It is to install a complete pu mping equipment on the chassis of a self-propelled vehicle to perform HP water supply operations. The device consists of two parts: chassis an d top-mounted equipment. In addition to completing the vehicle transfer function, the chassis also provides power for the bodywork leveling h ydraulic system; the top-mounted structure is the working part of the mobile intelligent HP pumping system: composed of diesel engine, clutch gearbox, HP pump, suction and discharge manifold, safety system, fuel system, lubrication system, circuit system, hydraulic system, instrumen t and control system.

Product characteristics

The working principle of the emergency smart water tender is to level the bodywork through the diesel engine power of the chassis vehicle to d rive the hydraulic system of the platform; the power generated by the start-up of the diesel engine on the platform is transmitted to the lift pu mp through the clutch gearbox and coupling, and the lift pump is driven to work; the feed water supplied by the feed pump can enter the lift pu mp through the filter from the suction pipeline, and is discharged by the HP discharge pipe once pressurized by the lift pump for emergency HP water supply operation.

Product parameter

Emergency smart water supply vehicle main parameters

Overall Dimension (L*W*H) 8165mmx2550mmx3500mm

Vehicle weight 24000kg<20s

Top speed 85km/h

Cab seating capacity 2

Max. lift 1,800m (corresponding flow rate of 20m³/h)

Max. flow 65m³/h (corresponding head of 1,070m)

Maximum power of lift pump 415kw

Product introduction

The emergency communication system based on the space platform is used after the occurrence of natural disasters. It has used the tethered a ir-boat ball to carry 4G/5G equipment to realize long-distance and large-area communication data coverage, avoid terrain occlusion, and solve the transmission of emergency voice communication and image data. Quickly establish a communication network in disaster-stricken areas, i mprove the efficiency of rescue command, and ensure the communication needs of personnel in disaster-stricken regions. As an air platform, t he tethered airship has the characteristics of flexible deployment, long-term fixed-point stationing in the air, adjustable altitude maneuverabili ty and strong mission payload capacity. It can choose the stationing altitude as required for the mission and regional weather conditions to co mplete specific tasks with the best performance, and has obvious advantages in emergency communication support.

Main function

1.Liftoff function: The function of lifting the mission payload to a predetermined altitude by a tethered airship.

2.Communication function: Send ground equipment data to mission payload and mission payload data to ground equipment.

3.Power transmission function: Transmit ground power to mission payload through the power supply system to meet the power demand of th e normal operation of the load.

4.High-voltage transmission function: Equipped with a boost module and high-voltage transmission function.

5.Stay in the air function: realize the continuous stay in the air work function of the mission payload (communication equipment) through the t ethered airship.

6.Airship retracting function: equipped with main winch system, universal pulley and auxiliary winch, and with the functions of releasing, tethe ring and recovering the tethered airship.

7.Anchorage function: equipped with rotary platform, hydraulic outrigger, mooring tower and horizontal support arm, and with the mooring fu nction of moored airship.

8.Maneuvering function: equipped with a semi-trailer chassis and mooring system with a maneuvering function.

9.Monitoring function: equipped with monitoring system, control cabin and console, with system monitoring function.

10.Temperature adjustment function: configured with air conditioning system, with shelter temperature adjustment function.

11.Night operation function: equipped with lighting group, with night operation function.

12.Warning function: in the anchoring state, the hydraulic outrigger, anchoring platform and horizontal arm are equipped with warning and cle arance lamps, with night warning function.

13.Power-off protection function: UPS module equipped with power-off protection function.

14.Lightning protection function: both air and ground portions equipped with lightning protection systems, with lightning protection functions.

Product characteristics

1.The carrier (tethered airship) is equipped with 4G base station and back-haul to realize air communication function.

2.The height of airship can reach up to 1,300m. By optimizing the structure of the airship, the maximum wind resistance is 20m/s when moored in the air, and the maximum wind resistance is 25m/s when anchored on the ground, so as to ensure the safety of high-altitude use.

3.The anchoring vehicle is used for anchoring, lifting and recovery functions, and the photoelectric composite cable is used for force traction an d transmission of photoelectric signals to ensure that the airship can retract and work normally, and realize air communication functions at diff erent heights.

4.AC380V/50HZ on the ground is converted into DC1000V after rectification and boosting, and transmitted to the ball through the photoelectric composite cable. The power supply on the ball converts the DC1000V receiving the photoelectric composite cable into DC28V, DC24V and other forms of secondary power supply for the ball equipment and mission payload.

5.Equipped with airship management system and air monitoring system, the Product can monitor the environmental high-altitude operation s tatus in real time and transmit the collected information to the command and decision-making system in time.

6.The outrigger realizes one-key operation to control the deployment and withdrawal of the outrigger, and the status of the outrigger is graspe d through the horizontal sensor to realize automatic leveling and ensure the safety of equipment use.

7.Using CAN bus control mode, through the interconnection between the mooring vehicle operating platform and each subsystem, the moorin g tower, main winch, and side winch CAN be controlled in the working cabin to achieve recovery.

Product introduction

8x8 all-terrain multi-functional fire truck 8x8 adopts 8-wheel drive mode, convertible and load-bearing body, and no-suspension structure type. Tarpaulin rod and canopy are optional with seating capacity of 6. The Vehicle consists of power system, integrated transmission system, electri cal system, braking system, driving system, control system, bodywork system, interior and exterior trim and top-mounted system, and can be e quipped with small-sized communication equipment for communication with the command center.

The 4x4 all-terrain multi-functional fire truck is light in weight and compact in size, and has a heavy load, with excellent all-terrain trafficability. It can quickly pass through complex regions such as mountains, jungles, beaches, deserts, snow and swamps; and can be directly loaded by tra nsport aircraft and helicopters and put into use quickly. It is mainly used in patrol, logistics support, personnel transportation, investigation, co mmand, emergency support and the like fields

Main function

1.[Wireless Communication Function]

Multiple Guarantee for Private Network Communication

Using voice communication means such as ultra-short wave and satellite telephone, the emergency communication function between the sce ne and the command center can be realized.

2.[Multi-terrain application]

Field occupation for flexible operation

It can quickly pass through complex regions such as mountains, jungles, beaches, deserts, snow and swamps

Product parameter

8x8 all-terrain multi-function fire truck main parameters

L*W*H (mm) 3900X 1800X1900

Wheelbase (mm) 760<20s

Minimum Ground Clearance (mm) 250

Complete Vehicle Kerb Mass (kg) 1800

4x4 all-terrain multi-function fire truck main parameters

L*W*H (mm) 3150X1700X2100

Wheelbase (mm) 1940

Wheelbase (front/rear) (mm) 1345/1350

Drive form PART-TIME 4WD

Product introduction

Emergency equipment transport vehicles mostly use mature truck chassis as a modification platform, which is widely used in the transportatio n of various fire-fighting equipment.

Main function

1.Modular design

2.Cloud management platform

3.Safe and reliable

4.Unmanned (remote) on duty

5.Good heat dissipation and sound insulation

Product parameter

Main parameters of emergency power supply vehicle

Chassis brand and model Qingling, Dongfeng, Sinotruck, MAN, etc.

Boundary Dimension (L*W*H) (mm) (6000-12000) x(2200-2500) x(3200-3900)

Gross mass (T) 8-31

Generated Power (kW) 50-1000

Product introduction

8x8 all-terrain truck 8x8 adopts 8-wheel drive mode, convertible and load-bearing body, and no-suspension structure type. Tarpaulin rod and c anopy are optional with seating capacity of 6. The Vehicle is composed of power system, integrated transmission system, electrical system, bra king system, driving system, control system, bodywork system, interior and exterior decoration and top-mounted bodywork system.

The 4x4 all-terrain truck is light in weight and compact in size, and has a heavy load, with excellent all-terrain trafficability. It can quickly pass t hrough complex regions such as mountains, jungles, beaches, deserts, snow and swamps; and can be directly loaded by transport aircraft and helicopters and put into use quickly. It is mainly used for patrol, anti-terrorism, logistics support, personnel transportation, investigation, com mand, emergency support and other aspects, and can be used as special area teams and individual patrol vehicles.

Product parameter

8x8 all-terrain multi-function fire truck main parameters

Chassis Model 8x8 ATV

Overall Dimension (L*W*H) (mm) 3900x1800x1800

Full Loaded Mass (kg) 2850

Tractive Mass (kg) 500

Maximum speed on water (km/h) 5

Maximum speed (km/h) 60

Maximum cruising range (km) 400

Number of passengers (persons) 6

4x4 all-terrain multi-function fire truck main parameters

Chassis Model 4x4 all-terrain truck

Overall Dimension (L*W*H) (mm) 3100x1700x2000

Full Loaded Mass (kg) 1550

Tractive Mass (kg) 300

Maximum speed on water (km/h) 400

Maximum speed (km/h) 90

Maximum cruising range (km) 250

Number of passengers (persons) 3
