| VDAO单缸半封闭 | VDAO单缸全封闭 | VDAO单缸半封闭 | VDAO单缸半封闭 | |
| Overall dimensions （L×W×H）mm | 4365×1680×1950 | 4300×1680×2060 | 4700×1900×2190 | 4450×1800×2600 |
| Dimensions of the cargo body（L×W×H）mm | 2700×1600×500 | 2500×1600×450 | 3000×1900×（500+500） | 3000×1800×500 |
| Wheel base（mm） | 2875 | 2855 | 3100 | 3500 |
| Wheel track（front /rear）（mm） | 1304 | 1340 | 1530 | 1670 |
| Min. ground cleara nce(mm） | 240 | 240 | 200 | 280 |
| Curb weight（kg） | 1610 | 1380 | 1850 | 1910 |
| Persons in cab（pe rsons） | 2 | 2 | 2 | 2 |
| Gross vehicle weigh t（kg） | 5370 | 5140 | 7110 | 6170 |
| Max. speed（km/h） | 15 | 15 | 15 | 15 |
| Min. turning radius （m） | 4.07 | 4.04 | 4.40 | 4.95 |
| Engine Type | CCZS1115B-CK | CCZS1115B-CK | CCZS1125/CCL32 | CCCZ480Q |
| Displacement（L） | 1.194 | 1.194 | 1.473/1.659 | 1.808 |
| Rated horsepower （kg.m/rpm） | 22 | 22 | 28/32 | 42 |
| Steering gear Type | Worm Wheel Steering | Worm Wheel Steering | Recirculating Ball Steering | Worm Wheel Steering |
| Front wheel | 6.00-16 | 6.00-14 | 6.50-16 | 6.00-16 |
| Rear wheel | 7.50-16 | 7.50-16 | 7.00-16Double Tyre | 7.00-16Double Tyre |
| Rated voltage | 12V | 12V | 24V | 24V |
| Battery | CK6-QW-120MF | CK6-QW-120MF | Double 6-QW-80MF | Double 6-QW-80MF |
| Containers | 9 | 8 | 8 | 8 |
| Other configuratio ns | 可选 |
